RK3288 Android 10 Mini Size Motherboard For POS Vending Media Player Advertising Machine

Certification
China SHENZHEN SUNCHIP TECHNOLOGY CO., LTD certification
China SHENZHEN SUNCHIP TECHNOLOGY CO., LTD certification
Customer Reviews
Awesome news! I know your team has worked hard, thanks for finish the project so quickly.

—— Brian Walker

I like your sample very much. Looking forward to growing our partnership.

—— Jenny Westbrook

I'm Online Chat Now

RK3288 Android 10 Mini Size Motherboard For POS Vending Media Player Advertising Machine

RK3288 Android 10 Mini Size Motherboard For POS Vending Media Player Advertising Machine
RK3288 Android 10 Mini Size Motherboard For POS Vending Media Player Advertising Machine RK3288 Android 10 Mini Size Motherboard For POS Vending Media Player Advertising Machine RK3288 Android 10 Mini Size Motherboard For POS Vending Media Player Advertising Machine RK3288 Android 10 Mini Size Motherboard For POS Vending Media Player Advertising Machine RK3288 Android 10 Mini Size Motherboard For POS Vending Media Player Advertising Machine

Large Image :  RK3288 Android 10 Mini Size Motherboard For POS Vending Media Player Advertising Machine

Product Details:
Place of Origin: China
Brand Name: RK3288 motherboard
Certification: CE, ROHS, ISO9001,ISO14001,ISO27000
Model Number: AD-Z37
Payment & Shipping Terms:
Minimum Order Quantity: 2pcs
Price: Negotiation
Packaging Details: anti-static bag, 1pc/bag
Delivery Time: 1-30days
Payment Terms: TT/PAYPAL
Supply Ability: 10000P/M

RK3288 Android 10 Mini Size Motherboard For POS Vending Media Player Advertising Machine

Description
Usb: 5 X USB Storage Temperature Range: -20°C To 80°C
Power: 12V/2A Sd Card: Support Up To 64GB
Wifi: 2.4G Or 2.4G & 5G,optional Screen Voltage: Support 3.3V/5V/12V Optional
Expansion: Micro SD Card Slot Ports: Ethernet, 4G, Wireless Wifi, BT, HD, Audio, SIM, USB, UART, RS232,etc
CPU: RK3288 RAM: 2GB / 4GB Optional
ROM: 16GB/ 32GB / 64GB Optional

RK3288 Android 10 Mini Size Motherboard For POS Vending Media Player Advertising Machine

Product Description:

Z37 is a smart solution adopts with RK3288 quad core chipset,running android 10 / 9.0/Android 7.1 /Android 6.0 OS,Linux OS can also be supported.

Integrated with multimedia decoding,LCD driving,Network functions,amplifier in one board.

It compatible with most of popular video&audio format,support display 4K video,could be use as android box for media displaying.

Comes with features : High integrated, High definition,Build in amplifier,Rich function interfaces ,Easy management.



This smart android board integrated with smart OS and rich function interfaces on one board,

Is great suitable for applying on high definition network media box, advertising displays, frame displays,interactive displays,security system,and smart industrial control. etc.



Features:

High Integration: Integrated with USB LVDS Ethernet HDMI WIFI, All-in-one, Simplifies Integral Machine design, with TF card slot.

Android 7.1 8.0 9.0 Operation System, 2G+16G

High Resolution: Supports 1080P/H.265(4K2K) Video decoding and various LVDS output LCD Display Screen.

With Audio Amplifier: Supports Dual channel amplifier 3W*2

Rich Interfaces: Support USB, Serial Port, ADC, suitable for mainstream AD machine in the market.

Full Function, Support display screen both landscape and portrait, Video split screen, rolling word screen, On/Off Timing,Data Transfer through USB.

Easy Management:Humanization software for playlist making, for advertising-display management and control easily. With advertising-display record, which make it easy to check AD display status. It's widely used in gaming machine, industrial display, medical, transportation display,banking ATM, touch solution, KIOSK, digital signage, industrial self-service automation, etc

RK3288 Android 10 Mini Size Motherboard For POS Vending Media Player Advertising Machine 0RK3288 Android 10 Mini Size Motherboard For POS Vending Media Player Advertising Machine 1RK3288 Android 10 Mini Size Motherboard For POS Vending Media Player Advertising Machine 2

Technical Parameters:

CPU:Rockchip RK3288 Quad-core Cortex-A17 Quad-core GPU Mali-T764

Main Frequency: 1.8 GHz

Deposit: LPDDR3 2G/4G Optional

Built-in Storage Capacity: EMMC 8GB/16G/32G/64G etc. optional

Display Interface:

LVDS Interface (single-channel, 6-bit dual-channel, 8-bit dual-channel). Support maximum resolution 1920x1080, support 7"-82" display

EDP Interface Maximum Resolution 4K

Screen Voltage: Support 3.3V/5V/12V optional

Touch Screen: Support I2C Touch Screen, USB Multi-point Infrared Touch Frame, Resistance, Capacitive Touch Screen.

The Internet

With RJ45 Interface, Support 10/100M Ethernet.

Equipped with Wifi &BT Module, Supporting Wi-Fi 802.11b/g/n Protocol. Support BT4.0

With 4G Module, Support 4G Network

Image Rotation: Support 0 Degree, 90 Degree, 180 Degree, 270 Degree Manual/Auto Rotation, Support Gravity Sensor Function (optional)

Real Time Clock: External Real-time Clock Power Supply Battery

Interface Device:

Support MIPI Camera

Support HDMI Output

5 USB HOST (support USB Camera@500W USB Printer, U Disk, Mouse, Keyboard and Standard USB Peripherals)

3 Groups of Serial Ports (1 Group of UART; 2 Groups of Standard UART or Optional RS232). Support External Serial Devices (NFC Module, Printer, Card Reader, etc.)

3 IO Detection Ports

TF Card

D Class Large Built-in Speaker, 5W*2 8R

Support Microphone

Audio: MP3,WMA,WAV, APE, FLAC, AAC, OGG,M4A,3GPP Format

Video: Support H.264, MPEG2, VP6, VP8, MVC and Other Video Formats 2160P@24FPS Decoding. YouTube and Other Online Videos, Up to 4K, HTML5 Video Playback, Flash 10.1 Playback

Image: Support JPG, BMP, PNG and Other Image Format Browsing and Support Rotation/Slide Show/Picture Zoom Function

Power Adapter:

Input:AC100-240V.50-60HZ, Output: DC12V 3A



Basic software specifications:



operating system Android 5.1 and above, up to Android 10
Basic software functions Web browsing, web chat, email, e-book, resource manager
Sound effect mode Clock, alarm clock, calculator, recording
language support multi-lingual
recording Support MP3, WMA format recording 3gpp, arm and other formats, according to the recording APK is different, the format is different, now the system comes with the arm format

tool











Calendar
Alarm Clock
Calculator
Note
Weather + clock
Recording
Word processing EPUB, WORD, EXCEL, POWERPOINT, PDF, TXT
E-book PDF/TXT/CHM/DOC/EXCEL/EPUB/RTF/FB2
schedule Calendar
Input Standard Android keyboard, optional third-party input method (Chinese, Korean, Japanese, etc.)

The internet





Browser -Chrome Lite
Email
Gmail
System Management APK installer
Original ecological Android system, open root permission, can carry out product customization development
Real-time remote monitoring, self-recovery from system crashes, 7*24 hours unattended
System setting
Global time
Support OTA remote upgrade


Applications:

Application Field

The following are examples of commercial machines that are used for advertising:

• Commercial advertising display machine

• POS machine

• Digital photo frame advertising machine

• Touch all-in-one machine

• Self-service vending machine
















Product Size:
Packed with static bag
RK3288 Android 10 Mini Size Motherboard For POS Vending Media Player Advertising Machine 3RK3288 Android 10 Mini Size Motherboard For POS Vending Media Player Advertising Machine 4




RK3288 Android 10 Mini Size Motherboard For POS Vending Media Player Advertising Machine 5




About Sunchip :


SUNCHIP is an OEM / ODM factory, customizing products to tailor your needs is our strength and mission, over 130 employees’ team that including over 70 research and development engineers, who can provide services and solutions in electronic Android mainboard design for digital signage industries and domains as it is becoming a critical function in the product development life cycle, diverse categories of embedded systems such as industrial automation, consumer electronics, embedded digital signage devices and exhibition display screen.





We focus on Rockchip chipsets solution and in-depth development, also deep customization of Android OS; Specialized on LCD Digital Signage & Android ARM Board.





Sunchip is a national high-tech enterprise with various patents. Our factory runs under the ISO 9001 & ISO 14001 certification. Our products fully completely with CE, RoHS and FCC certifications.



Sunchip has become the ODM / OEM partner of a number of world-class companies. Our products have been exported to over eighty worldwide countries.We do the best we can consistently to provide excellent quality products and one-stop services for all customers.

We are looking forward to cooperating, developing and growing with you sincerely.





RK3288 Android 10 Mini Size Motherboard For POS Vending Media Player Advertising Machine 6





We mainly manufacture



1, Android industrial Embedded board: RK3588, RK3566, RK3568, RK3288, RK3399,

RK3328, RKPX30, RK3188, RK3128 etc.

2, 【4K】Android media player box for digital signage advertising: RK3399, RK3288, RK3328.

3, 【8K】Android Player Box for Industrial-Control Application: RK3588.

4, Stretched lcd Display signage, support ODM.

5, Open frame LCD display signage: 8inch, 10.1inch, 13.3inch, 15.6inch, 21.5inch etc.

6, SKD Kit: Android board + LCD panel with touch or not:

7inch, 8inch, 10.1inch, 13.3inch, 15.6inch.

7, Other types of Wall Mounted / Floor Standing / Desktop LCD digital signage.

8, Embedded touch desk: such as 32inch.

9, Face recognition temperature detection terminal machine: such as 8inch.



[you can also tell us your requirements, so that we advise you a matched solution]
