|CPU&GPU:||RK3399 Six-core||LCD Screen:||13.3''|
|Operating System:||Android 7.1.2 (optional)||4G LTE:||Support 4G(optional)|
|WiFi:||802.11b/g/n （2.4G/5G Optional）||Network:||10M/100M/1000M Ethernet;|
open frame lcd screen,
open frame lcd monitor
Sunchip 13.3 inch open frame lcd display metal digital signage advertising player retail restaurant store shopping mall
Intelligent industrial all in one board, using Rockchip RK3399 six-core chip program, support Google Android7.0 or higher system. Powerful computing power. Support H.265 4K video playback. Rich interface and enhanced power management circuit. Suitable for intelligent remote network control: industrial, medical, large advertising, educational video terminals and other equipment.
a, It also supports 7-inch to 84-inch LVDS interface displays (point-to-point full HD display 1920*1080) and EDP interface display.
b, Multiple interactive mode interfaces: capacitive touch, infrared touch, infrared remote control, USB mouse and keyboard, multi-point optical touch.
c, A variety of network interfaces: Ethernet, 4G, WIFI, Bluetooth.
d, Multi-channel USB interface, serial output.
e, Support 4K video play
f, Strong anti-electromagnetic interference and electromagnetic compatibility.
13.3 inch Wall Frameless LCD Panel Open Frame LCD Monitor
1. Open frame structure: with customizable and changeable metal frame to embedded into your furniture, store shelf, showcase, or fit into any object as per your design.
2. With built-in any inches TFT LCD screen, plays from SD card or USB Stick, or remote control system.
3. Our structure engineers can help you with design service as per your special need.
4. Industrial-grade design, heavy-duty built for non-stop loop-playing HD video and picture 24/7/365.
5. Plug & Play, very easy to use
6. Upload contents to the memory card by one-step inserting an USB flash drive; no need to pull out the memory card; no need to use a laptop.
7, With our remote controlling system, user can publish any contents to the devices wherever at home or at the office that far away from the open frame LCD display.
7. Timer function: the player powers on / off automatically every day at your pre-set time.
8. No DVD-style mechanical movement, hence more durable and suitable for long-hour advertising playing.
RK3399 Six-Core Android 7.1.2. (Linux OS optional)
-Open Frame Series
Basic Hardware Specifications:
|CPU||Rockchip RK3399 daul core Cortex-A72+quad-core Cortex-A53 CPU|
|GPU||ARM Mali-T860MP4 GPU|
|RAM||DDR3 2G/4G Optional|
|Built-in storage capacity||EMMC 8GB/16G/32G/64G Optional(Label 8GB)|
|Display interface||LVDS interface (single, 6 dual, 8 dual). Support the maximum resolution of 1920x1080, support 7 "-84" display|
|EDP screen interface, support for resolution 1920x1080|
|Onboard backlight||Support 3.3V/5V/12V Optional|
Provide I2C interface (can support multi-point resistance touch, multi-point capacitance touch).
Support USB multi-point infrared touch, multi-point acoustic touch, multi-point optical touch.
|Internet||With RJ45 interface, support for 10/100 Ethernet|
|With Wifi & BT module, support for Wi-Fi 802.11b / g / n / ac protocol. Support BT4.0|
|Image rotation||Support 0 degrees, 90 degrees, 180 degrees, 270 degrees manual / automatic rotation, support for gravity sensing|
|Real Time Clock||Built-in real-time clock battery|
|Interface equipment||Support MIPI interface camera, up to 500W pixels|
|Support USB camera|
|4 USB HOST, 1 USB OTG (support POE power supply)|
|3 groups of serial port. Supports external serial device devices (3G module, NFC module, printer, swipe card reader, etc.)|
|3 IO test port|
|SD card, maximum support 64GB|
|Class D amplifier: 1.5W * 2 8 ohm, support for the microphone|
|Audio||MP3,WMA,WAV, APE, FLAC, AAC, OGG,M4A,3GPP format|
|Video||Support for 2160P @ 24FPS decoding of video formats such as H.264, MPEG2, VP6, VP8, MVC, etc. Online videos from YouTube, up to 1080P, HTML5 video playback, Flash 10.1 playing.|
|Picture||Support for JPG, BMP, PNG and other image formats Browse and support rotation / slide show / image zoom function|
|Power Adapter||Input:AC100-240V.50-60HZ, Output: DC12V 3A|
Basic Software Specifications:
|Operating system||Google Android 7.0|
|Basic software features||Web browsing, web chat, e-mail, e-books, resource managers|
|Sound mode||Clock, alarm clock, calculator, recording|
|Voice support||Multi-national voice|
|Recording||Support MP3, WMA format recording|
|Weather + clock|
|File processing||EPUB, WORD, EXCEL, POWERPOINT, PDF, TXT|
|Input method||Standard Andriod keyboard, optional third-party input method (Chinese, Korean, Japanese, etc.)|
|System Management||APK Installer|
|Original Android system, open root privileges, product development can be customized|
|Real-time remote monitoring, system crash self-recovery, 7 * 24 hours unattended|
|Support OTA remote upgrade|
Wooden case *1 (if necessary)
