Product Details:
|
| CPU: | RKPX30 | Display: | LVDS, MIPI Optional |
|---|---|---|---|
| Panel: | 55'' | OS: | Android 8.1 |
| Resolution: | 1920*1080 | G-sensor: | Support |
| RAM: | DDR3 1G/2G Optional | ROM: | EMMC 8GB/16G/32G/64G Optional (default: 8GB) |
| Touch Screen: | 10 Point Capacitive Touch | Ethernet: | RJ45, Support 10/100/1000M Ethernet |
| WIFI/Bluetooth: | 802.11 B/g/n/ac (optional); BT Available; | ROOT Permission: | Support |
| High Light: | wall advertising display,wall mounted digital signage |
||
55 inch LCD wall mounted video advertising media player display with touch screenWIFI Ethernet ram rom optional
Wall Mounted Digital Signage from SUNCHIP
Overview:
Android integrated board, using Rockchip PX30 quad-core chip solution, support Android 8.0 system. Supports the decoding of the popular audio & video formats and images. The multi interface makes the product in common use and is widely used in intelligent control fields such as advertising machines, all-in-one PC, security, industrial and so on.
Feature
-- Support Dual LVDS; MIPI; display interface; support 7 inch to 10.1-inch Dual LVDS display interface (point-to-point full HD display 1920*1080).
-- Multiple interactive mode interfaces: capacitive touch, infrared touch, infrared remote control, USB mouse and keyboard, multi-point optical touch.
-- Multiple network interfaces: Ethernet, wireless Wi-fi, Bluetooth.
-- Multi-channel USB interface, serial port, IO port output.
-- Strong resistance to electromagnetic interference and electromagnetic compatibility.
Product Details:
Hardware Specifications:
| CPU | Rockchip PX30 Quad-core Cortex-A35 Mali-G31 MP2 GPU |
| Frequency | 1.5GHz |
| RAM | DDR3 1G/2G optional |
| ROM | EMMC 8GB/16G/32G/64G optional (default: 8GB) |
| Display interface | LVDS optional |
| MIPI optional | |
| Touch Screen | Support USB IR multi touch, sonic multi touch, optical multi touch |
| Network | RJ45 interface, ethernet 10/100M |
WIFI& BT: support Wi-Fi 802.11b/g/n/, and support BT4.0 support | |
| RTC | Built in internal battery for Real time clock |
| Interfaces | Support USB camera |
| 3*USB HOST,1*USB OTG | |
| 3*Serial ports, support external devices (NFC module, printer, card reader etc.) | |
| Support MIPI camera, max 8MP | |
| D classamplifier,5W*2 8R | |
| support microphone *1 | |
| Audio | MP3, WMA, WAV, APE, FLAC, AAC, OGG, M4A,3GPP format |
| Video | Support H.264, MPEG2, VP6, VP8, MVC, 2160P@24FPS decoding. on-line video such as YouTube, max support 4K,HTML5 playback,Flash10.1 playback |
| Images | Support JPG,BMP,PNG etc. picture formats, browse, orientation, slides, magnify |
| Power supply | input:AC100-240V.50-60HZ, output: DC12V-3A |
Software Specifications:
| OS | Google Android 8.1 |
| Basic software functions | Web browsing, web chat, e-mail, e-books, and resource managers |
| Sound mode | Clock, alarm clock, calculator, recording |
| Language | Multi language |
| Recording | Support MP3, WMA, 3gpp, Amr, etc., the system comes with an Amr format |
| Tools | Calendar |
| Alarm Clock | |
| Calculator | |
| Note | |
| Weather Clock | |
| Recording | |
| Document | EPUB, WORD, EXCEL, POWERPOINT, PDF, TXT |
| E-book | PDF/TXT/CHM/DOC/EXCEL/EPUB/RTF/FB2 |
| Schedule | Calendar |
| Input methods | Standard Android keyboard, optional third-party input method (Chinese, Korean, Japanese, etc.) |
| Internet | Browser -Chrome Lite |
| Gmail | |
| System Management | APK Installer |
| Original eco-Android system, open root privileges, can be customized product development | |
| Real-time remote monitoring, system crash recovery automatically, 7 * 24 hours unattended | |
| Support OTA remote upgrade | |
| System setting | |
| Google Maps | |
| Global time |
