Product Details:
|
| Advantage: | Small, Convenient To Install, Connect And Operate | Application: | For Industrial Grade Application |
|---|---|---|---|
| RAM: | 2GB/4GB (optional)--defaulted 2GB RAM | ROM: | 16GB/32GB(optional)--defaulted 16GB ROM |
| CPU: | RK3288W Quad-core Cortex-A17 @1.8G GPU Mali T764 | Housing: | Metal Box |
| OS: | Android 6.0, 7.1, 9.0 | Networks: | WIFI, BT, LAN, 4G Optional |
| High Light: | Media Player Box 4G Optional,EDP Media Player Box,LVDS Digital Signage Media Player |
||
Quad-core RK3288 Android Decoding Driver Integrated Board/Media BOX
This Android digital multimedia player with a 9.0 operating system has 2G/4G RAM making for high-speed streaming and operation to help you make the most out of your devices.
With 16G/32GB of embedded memory, you will be able to create impactful in-store advertising campaigns, download more media and apps, have faster response times, and evolve the way you are sharing and storing content.
This commercial Android digital multimedia player has H.265 decoding providing you with smooth video play using less bandwidth for a beautiful visual experience that will help you share impactful advertising campaigns with ease.
Google Play Store access allows you to download your apps directly to your devices without any complicated uploads or long wait times.
This commercial Android digital multimedia player with a 6.0/7.1/9.0 operating system is faster than ever before.
It will bring efficiency to your install promotions, corporate presentations, and even improve your own personal devices, whether you are watching movies or playing games!
Quickly turn your TVs, Monitor and other displays into eye catching digital signage for your business or organization. If you want a great Digital Signage Media Player, then AD-B02P BOX is the best choice you can make.
Digital signage doesn't have to be complicated or expensive.
AD-B02P BOX lets you use any TV to get your message across in an attractive way.
Schedule, manage and upload content to your screens at the click of a button, all from your browser.
Easily display your latest offers, share company news, products and service in video/image/website/scrolling text,
and much more.
Product Specifictions:
| Hardware Spec | ||||||
| System | CPU&GPU | RK3288 Quad-core Cortex-A17 @1.8G GPU Mali T764 | ||||
| RAM | 2GB/4GB (optional) | |||||
| Memory | 8GB/16GB/32GB(optional) | |||||
| Operating system | Android 6.0(Linux optional) | |||||
| Network | WiFi | 802.11b/g/n(2.4G/5G optional) | ||||
| Mobile network | Support full Netcom 4G (optional) | |||||
| Bluetooth | Bluetooth 4.0 | |||||
| Ethernet | 10M/100/1000M Ethernet | |||||
| Language | Multi-Language support | |||||
| Interface | ||||||
| Interface | USB interface | Support USB host*2 | ||||
| Micro USB | USB_Debug interface*1 | |||||
| DC | DC power 12V input | |||||
| SD card | Maximum support 64GB | |||||
| HDMI | Support HDMI output Support 4K 60FPS frame rate | |||||
| Screen interface | EDP screen interface / LVDS screen interface(optional) | |||||
| Speaker output | 8Ω*5W * 2(optional) | |||||
| UART | UART2*1(optional) | |||||
| infrared remote control | Support infrared remote control | |||||
| USB port expantion | USB port expandert*1(optional) | |||||
| RJ45 | 10/100/1000M Ethernet port | |||||
| Headset | 3.5mm stereo headphone output | |||||
| Media Parameter | ||||||
| Media Playback | Video format | MPEG-1,MPEG-2,MPEG-4,H.263,H.264,H.265,VC1,VP8,RV etc.,support up to 3840x2160 | ||||
| Audio format | MP3,WMA,WAV, APE, FLAC, OGG,M4A,3GPP format | |||||
| Text processing | EPUB, WORD, EXCEL, POWERPOINT, PDF | |||||
| Ebook | PDF,TXT,CHM,DOC,EXCEL,EPUB,RTF,FB2 | |||||
| Image Format |
JPG,BMP,PNG |
|||||
| System Management | ||||||
| System Management | APK install | APK installer | ||||
| Root permission | Original Android system, open root permissions, product customization development | |||||
| Remote control | Real-time remote monitoring, system crash self-recovery, 7*24 hours unattended | |||||
| OTA upgrade | Support OTA remote upgrade | |||||
| Accessories | ||||||
| Accessories | Adapter | Power adapter 12V/2A | ||||
| User's Guide | Standard | |||||
| Warranty Card | Standard | |||||
| Size(unit:mm) | ||||||
| Product size(L*W*H) | 195*100*20 | |||||
| colour box size(L*W*H) | ||||||
| Carton size(PCS/CTN)(L*W*H) | ||||||
| Others Parameters | ||||||
| Double screen display | Support Double screen display(optional) | |||||
| Gravity induction | Support 0°90°180°270°manual automatic rotation | |||||
| working temperature | ||||||
| laboratory temperature | ||||||
Industrial player for advertising 24/7
Advertising media box 2GB+16GB WIFI/BT/LAN/4G Android OS
Android Digital Signage Advertising Media Player Box android 7.1-10.0
digital signage advertising 4k player Box
Industrial Looping Digital Signage Media Player Box support wifi bt lan 4G optional metal box lvds edp hd output
1, Android board for industrial digital signage,
(RK3288, RK3399, RK3328, RKPX30, RK3188, RK3128, RK3566 and RK3568, ...)
2, Android digital signage media player box, (RK3328, RK3288, RK3399)
3, Stretched lcd display signage,
4, Open frame lcd display signage, (Such as, 10.1’’, 15.6’’, 21.5’’, …)
5, Other types wall/desktop/standing lcd digital signage, (from 7’’ to 84’’, ...)
6, Embedded touch desk, (Such as, 32-inch, ...)
7, Face recognition temperature detection and attendance equipment, (8-inch)
8, CMS system. (Publish contents/programs by remotely.)
1. So far, there are more than 10 years of PCBA design and production experience.
In 2022, we had the 10th Anniversary Celebration.
2. A R&D team with more than 80 people, including hardware engineers (layout boards, debugging, etc.), software engineers (driver, kernel, test and apk engineers), ID design, mechanical design engineers, support OEM/OEM
3. The whole team has about 160 people.
4. One-stop service: product definition, schematic design, PCB layout design,
prototype, production, PCBA SMT, test production, housing design, assembly, software customization, QC control, after-sales etc.
5. Passed ISO9001 factory certification
6. There are more than 3,800 square meters of office and workshop area, which is still expanding.
WELCOME TO CONTACT US FOR THE PRODUCT INQUIRY!
SUNCHIP mainly manufactures:
1, Android industrial Embedded ARM board: RK3588, RK3566, RK3568, RK3288, RK3399,
RK3328, RKPX30, RK3188, RK3128 etc.
2, 【4K】Android player box for digital signage advertising: RK3399, RK3288, RK3328 & RK3568.
3, 【8K】Android Player Box for Industrial-Control Application: RK3588.
4, Open frame LCD display signage: 8inch, 10.1inch, 13.3inch, 15.6inch, 21.5inch etc.
5, SKD Kit: Android board + LCD panel with touch or not:
7inch, 8inch, 10.1inch, 13.3inch, 15.6inch.
6, Other types of Wall Mounted / Floor Standing / Desktop LCD digital signage.
7, Embedded touch desk: such as 32inch.
8, Face recognition temperature detection terminal machine: such as 8inch.
[You can also tell us your detailed requirements, so that we advise you a matched solution]
