Product Details:
|
| CPU: | RKPX30 | Panel: | 55'' |
|---|---|---|---|
| OS: | Android 8.1 | Display: | LVDS, MIPI Optional |
| Touch Screen: | 10 Point Capacitive Touch | Resolution: | 1920*1080P |
| RAM: | DDR3 1G/2G Optional | ROM: | EMMC 8GB/16G/32G/64G Optional (default: 8GB) |
| WIFI/Bluetooth: | 802.11 B/g/n/ac (optional); BT Available; | Ethernet: | RJ45, Support 10/100/1000M Ethernet |
| High Light: | wall mount lcd display,wall mounted digital signage |
||
55 65 Inch Indoor outdoor Wall Mounted Lcd Digital Signage WIFI 4G Advertising Display Board 2GB RAM 8GB ROM Ethernet
Wall Mounted Digital Signage for supermarket shopping mall store etc.
from SUNCHIP
Overview:
Android integrated board, using Rockchip PX30 quad-core chip solution, support Android 8.0 system. Supports the decoding of the popular audio & video formats and images. The multi interface makes the product in common use and is widely used in intelligent control fields such as advertising machines, all-in-one PC, security, industrial and so on.
Feature
-- Support Dual LVDS; MIPI; display interface; support 7 inch to 10.1-inch Dual LVDS display interface (point-to-point full HD display 1920*1080).
-- Multiple interactive mode interfaces: capacitive touch, infrared touch, infrared remote control, USB mouse and keyboard, multi-point optical touch.
-- Multiple network interfaces: Ethernet, wireless Wi-fi, Bluetooth.
-- Multi-channel USB interface, serial port, IO port output.
-- Strong resistance to electromagnetic interference and electromagnetic compatibility.
Product Details:
Hardware Specifications:
| CPU | Rockchip PX30 Quad-core Cortex-A35 Mali-G31 MP2 GPU |
| Frequency | 1.5GHz |
| RAM | DDR3 1G/2G optional |
| ROM | EMMC 8GB/16G/32G/64G optional (default: 8GB) |
| Display interface | LVDS optional |
| MIPI optional | |
| Touch Screen | Support USB IR multi touch, sonic multi touch, optical multi touch |
| Network | RJ45 interface, ethernet 10/100M |
WIFI& BT: support Wi-Fi 802.11b/g/n/, and support BT4.0 support | |
| RTC | Built in internal battery for Real time clock |
| Interfaces | Support USB camera |
| 3*USB HOST,1*USB OTG | |
| 3*Serial ports, support external devices (NFC module, printer, card reader etc.) | |
| Support MIPI camera, max 8MP | |
| D classamplifier,5W*2 8R | |
| Support microphone *1 | |
| Audio | MP3, WMA, WAV, APE, FLAC, AAC, OGG, M4A,3GPP format |
| Video | Support H.264, MPEG2, VP6, VP8, MVC, 2160P@24FPS decoding. on-line video such as YouTube, max support 4K,HTML5 playback,Flash10.1 playback |
| Images | Support JPG,BMP,PNG etc. picture formats, browse, orientation, slides, magnify |
| Power supply | Input:AC100-240V.50-60HZ, output: DC12V-3A |
Software Specifications:
| OS | Google Android 8.1 |
| Basic software functions | Web browsing, web chat, e-mail, e-books, and resource managers |
| Sound mode | Clock, alarm clock, calculator, recording |
| Language | Multi language |
| Recording | Support MP3, WMA, 3gpp, Amr, etc., the system comes with an Amr format |
| Tools | Calendar |
| Alarm Clock | |
| Calculator | |
| Note | |
| Weather Clock | |
| Recording | |
| Document | EPUB, WORD, EXCEL, POWERPOINT, PDF, TXT |
| E-book | PDF/TXT/CHM/DOC/EXCEL/EPUB/RTF/FB2 |
| Schedule | Calendar |
| Input methods | Standard Android keyboard, optional third-party input method (Chinese, Korean, Japanese, etc.) |
| Internet | Browser -Chrome Lite |
| Gmail | |
| System Management | APK Installer |
| Original eco-Android system, open root privileges, can be customized product development | |
| Real-time remote monitoring, system crash recovery automatically, 7 * 24 hours unattended | |
| Support OTA remote upgrade | |
| System setting | |
| Google Maps | |
| Global time |
