Product Details:
|
| CPU: | Rockchip PX30 Quad-core Cortex-A35 Mali-G31 MP2 GPU | OS: | Google Android 8.1 |
|---|---|---|---|
| Panel: | 32'' | Display Interfaces: | LVDS, MIPI, Optional |
| RAM: | DDR3 1G/2G Optional | ROM: | EMMC 8GB/16G/32G/64G Optional (default: 8GB) |
| Touch Screen: | 10 Point Capacitive Touch | Ethernet: | RJ45 Interface, Ethernet 10/100M |
| WIFI/Bluetooth: | YES | G-sensor: | Support |
| ROOT Permission: | Support | OTA: | Support |
| High Light: | wall mount lcd display,wall mounted digital signage |
||
SUNCHIP ADW 32 Inch LCD panel wall mounted indoor lcd screen display FHD touch screen internet advertising display
Wall Mounted Digital Signage from SUNCHIP
Overview:
Android integrated board, using Rockchip PX30 quad-core chip solution, support Android 8.0 system. Supports the decoding of the popular audio & video formats and images. The multi interface makes the product in common use and is widely used in intelligent control fields such as advertising machines, all-in-one PC, security, industrial and so on.
Feature for wall mounted advertising display
-- Support Dual LVDS; MIPI; display interface; support 7 inch to 10.1-inch Dual LVDS display interface (point-to-point full HD display 1920*1080).
-- Multiple interactive mode interfaces: capacitive touch, infrared touch, infrared remote control, USB mouse and keyboard, multi-point optical touch.
-- Multiple network interfaces: Ethernet, wireless Wi-fi, Bluetooth.
-- Multi-channel USB interface, serial port, IO port output.
-- Strong resistance to electromagnetic interference and electromagnetic compatibility.
Product Details for wall mounted advertising display:
| Model No.: AD-32''-RKPX30 | Rockchip PX30 Quad-core Cortex-A35 Mali-G31 MP2 GPU (32'' Android retail tablets with touch screen ) |
|||||
| Hardware Spec | ||||||
| System | CPU&GPU | Rockchip PX30 Quad-core Cortex-A35 Mali-G31 MP2 GPU | ||||
| RAM | 1GB/2GB (optional) | |||||
| Internal Memory | 8GB/16GB/32GB(optional) | |||||
| Operating system | Android 8.1 | |||||
| Touch screen | 10 point capacitive touch(optional) | |||||
| Display | Panel | 32'' | ||||
| Resolution | 1920*1080 | |||||
Basic Hardware Specifications for wall mounted advertising display:
| CPU | Rockchip PX30 Quad-core Cortex-A35 Mali-G31 MP2 GPU |
| Frequency | 1.5GHz |
| RAM | DDR3 1G/2G optional |
| ROM | EMMC 8GB/16G/32G/64G optional (default: 8GB) |
| Display interface | LVDS optional |
| MIPI optional | |
| Touch Screen | Support USB IR multi touch, sonic multi touch, optical multi touch |
| Network | RJ45 interface, ethernet 10/100M |
|
WIFI& BT: support Wi-Fi 802.11b/g/n/, and support BT4.0 support (optional WIFI 802.11 a/b/g/n/ac 5G&2.4G) |
|
| RTC | Built in internal battery for Real time clock |
| Interfaces | Support USB camera |
| 3*USB HOST,1*USB OTG | |
| 3*Serial ports, support external devices (NFC module, printer, card reader etc.) | |
| Support MIPI camera, max 8MP | |
| D classamplifier,5W*2 8R | |
| support microphone *1 | |
| Audio | MP3, WMA, WAV, APE, FLAC, AAC, OGG, M4A,3GPP format |
| Video | Support H.264, MPEG2, VP6, VP8, MVC, 2160P@24FPS decoding. on-line video such as YouTube, max support 4K,HTML5 playback,Flash10.1 playback |
| Images | Support JPG,BMP,PNG etc. picture formats, browse, orientation, slides, magnify |
| Power supply | input:AC100-240V.50-60HZ, output: DC12V-3A |
Board Photos:
Office & Factory:
SUNCHIP: Digital Signage manufacturer in Shenzhen, China.
Our main products include Android ARM Board, Floor Standing Display, Wall Mounted Display, Stretched LCD Display, Open Frame Display and Android Media Player Advertising Box.
