Product Details:
|
| LCD Panel: | TFT 32'' | Resolution: | 1920*1080 LVDS/EDP/MIPI |
|---|---|---|---|
| CPU: | ARM Cortex-A9 Quad Core | DDR, EMMC: | 1G+8G |
| Display Operation Mode: | Normally Black | Viewing Angle (H / V): | Typical 178 / 178 |
| WIFI: | 2.4G IEEE 802.11a/b/g/n | Rotation Function: | Unachievable |
| USB: | OTG*1 (Micro USB), Micro USB *2 | TF Slot: | 1 *PUSH-PUSH TF Card Reader |
| High Light: | long lcd screen,ultra wide lcd display |
||
0.9m 90cm 35 inch stretched LCD long bar shelf edge LCD display digital signage advertising screen from sunchip
CHARACTERS:
· Resizing LCD (Stretched LCD, Bar LCD)
· Ultra-Wide Screen
· Wide View Angle
· Flexible Central Management System
· Multi-zone, Multi-media Display
· Web-based Scheduling and Content Management
· Simple to Install, Manage and Use
· Easy Deployment and Operation
· Slim Bezel
· Stretched LCD Monitor of 19,1’’, 21.9’’, 23.1’’, 28’’, 28.8’’, 35’’, 36.6’’, 38’’ etc. are available
· Support many media formats and animation text
· 365 x 24 hours working
PRODUCTS SPECIFICATIONS
| Item | Specification | Unit | |
|
Screen Parameters |
Active Area | 878.4 (H) x 48.19 (V) (35” wide diagonal) | mm |
| Max Resolution | 2880(H) x158(V) | / | |
| Bezel Opening Area | 880.4(Length) * 50(Width) | ||
| Frame rate | 60 | Hz | |
| Driver Element | a-Si TFT Active Matrix | / | |
| Pixel Number | 158 x 2880 | pixel | |
| Pixel Pitch (Sub Pixel) | 0.11025 (H) x 0.334(V) | mm | |
| Pixel Arrangement | RGB Vertical Stripe | / | |
| Display Colors | 1.07G colors (8-bit+FRC) | ||
| Display Operation Mode | Transmissive mode / Normally black | ||
| Surface Treatment | AG~40% / Hardness 2H | ||
| Rotation Function | Unachievable | ||
| Viewing Angle (H / V) | Typical 178 / 178 | degree | |
| Brightness | Typical 400 | cd/m2 | |
| Contrast Ratio | Typical 3000 | / | |
| Item | Specification | Remarks | |
|
Finished Device Parameters |
CPU | ARM Cortex-A9 Quad Core | |
| GPU | Mali 400 Quad. Cores 3D GPU | ||
| DDR | 1GByte LPDDR3 | Max Support 2GByte | |
| eMMC | 8GByte | Max Support 128GByte | |
| LCD | 35’’ stretched Display, 158*2880 resolution | ||
|
WIFI |
2.4G IEEE 802.11a/b/g/n |
||
| TF slot | 1 个 PUSH-PUSH TF card reader | Max Support 128GByte | |
|
Finished Device Parameters |
Item | Specification | Remarks |
| Microphone | no | ||
| keys | reset*1 | ||
| Camera | no | ||
| USB | OTG*1 (Micro USB), Micro USB *2 | ||
| Nominal Input Voltage | AC 100V-240V | ||
| Rated Frequency | 50/60Hz | ||
| Input Current | 2A | ||
| OS | Android 5.0 | ||
| Interface style | standard Android tablet UI | ||
| Format for pictures | JPG,JPEG,BMP,GIF,PNG etc formats | ||
|
Videos playing |
AVI, MOV, MKV, MP4, M4V, FLV, 3GP, 3G2,3GPP, MPG, Capability for video decoding:H.265(HEVC)4K2K@30fps, 1080P@30fps,H.264(BP/MP/HP level 4.1, 1080p@30fps), H.263(profile 3,1080p@30fps), MPEG-1(MP, 1920X1080@30fps), MPEG-2(MP,1920X1080@30fps), MPEG-4(ASP,1920X1080@30fps), Xvid (Home theater 1920X1080@60fps), MJPEG(baseline,1920X1080@60fps), Divx(3.11,1280x720@60fps)； |
||
| input | Support Android pinyin input | ||
| APK | Support third-party APK | ||
| Size | 891.6(Length) * 60.4(Width)*16.0 mm | ||
| Languages |
English, Chinese Simplified, Chinese Traditional, Japanese, Korean, French, German , Spanish, Portuguese, etc. 32 languages |
PACKAGING DETAILS
1, Packaging: film, foam and wooden case (international standard packaging), suitable for export.
2, Lead time: in 1 week for sample order, about 5 weeks for large order.
