Product Details:
|
| Product Type: | Android All In One Advertising | Product Description: | 19.1 Inch Android All In One Advertising |
|---|---|---|---|
| CPU/GPU: | RK3288 Quad-core Cortex-A17@1.8G GPU Mali T764 | RAM: | 2GB/4GB (optional) |
| ROM: | 8GB/16GB/32GB(optional) | OS: | Android 6.0 |
| LCD Panel: | 19.1 Inch | Resolution: | IPS 1920*338 |
| Contrast Ratio: | 1000:1 | Brightness: | 700cd/m2 |
| Aspect Ratio: | 16:2.8 | WiFi: | 802.11b/g/n（802.11a/b/g/n/ac Optional） |
| Bluetooth: | Bluetooth 4.0 | Ethernet: | 10M/100/1000M Ethernet |
| Mobile Network: | Built In 3G/4G LTE(optional, Default None) | TF Card Slot: | Max Support 128GB |
| USB Type-C: | Support Upgrade And Debug | USB Interface: | USB Interface*2 |
| Root Permission: | Support | Remote Control: | Support |
| OTA Upgrade: | Support OTA Remote Upgrades | Gravity Sensor: | Support G-sensor |
| POE Function: | Support POE (optional, Default None) | ||
| High Light: | long lcd screen,ultra wide lcd display |
||
19.1 inch Advertising digital signage Stretched Bar Lcd display for the supermarket
RK3288 Solution Summary:
RK3288 Android integrated board, using Rockchip RK3288 quad-core chip solution, support Android5.1 system. Supports the decoding of the popular audio & video formats and images. Support EDP@4K, dual 8-bit LVDS interface 1920*1080, can drive 7" to 82" display. support 4K video playing. The multi interface makes the product in common use and is widely used in intelligent control fields such as advertising machines, all-in-one PC, security, industrial and so on.
Product Description for ultra-wide LCD display // Bar LCD display // Stretch LCD display:
Widely use on Airport, station, catering industry, entertainment industry, medical institution, golf course, supermarket, exhibition, stadium and gymnasium, financial industry, organ and enterprise, building adverting and billboard advertising, subway, hotel, rail way station, bus station, lift, bank, commercial center, wedding photograph, large exhibition, mobile show, chain-store and etc.
Main functions:
1. HD LCD screen, support display models of 16:3, (Horizontal/Vertical) etc.
2. Multi-groups of on/off time schedule could be stetted remotely and control the display through Internet.
3. Interactive optical multi-points touch function, touch in two points simultaneously.
4. Compatible multimedia file formats: MPEG1/2/4, AVI, RM, WMV,DAT, JPEG, BMP, PPT, WORD, EXCEL, TXT, MP3, RMVB, SWF etc.
5. Scrolling texts in English and Chinese version are available, various display modes for titles (Fonts and colors of letters, background colors, the relative attributes of rolling directions in horizontal or vertical could be adjusted).
6. Support media contents combine by videos, pictures, flashes, marquee etc.
7. Support uploading files through WIFI and Ethernet network.
8. Intelligent system for arranging and playing programs, easy and fast operation.
9. Support displaying in dual screens, play different video files and audio contents in these two screens.
PRODUCTS SPECIFICATIONS
| System | CPU | RK3288 Quad-core Cortex-A17@1.8G GPU Mali T764 | ||||||||||||
| RAM | 2GB/4GB (optional) | |||||||||||||
| Storage | 8GB/16GB/32GB(optional) | |||||||||||||
| Operation system | Android 6.0 | |||||||||||||
| Display | LCD panel | 19.1" | ||||||||||||
| Resolution | IPS 1920*338 | |||||||||||||
| Contrast ratio | 1000:1 | |||||||||||||
| Brightness | 700cd/m2 | |||||||||||||
| Aspect Ratio | 16:2.8 | |||||||||||||
| Network | WiFi | 802.11b/g/n(802.11a/b/g/n/ac optional) | ||||||||||||
| Bluetooth | Bluetooth 4.0 | |||||||||||||
| Mobile Network | Built in 3G/4G LTE(optional, default none) | |||||||||||||
| Ethernet | 10M/100/1000M Ethernet | |||||||||||||
| Interface | USB interface | support USB host*2 | ||||||||||||
| DC | DC power supply 12V input | |||||||||||||
| TF card | Maximum support 32GB | |||||||||||||
| RJ45 | Ethernet port | |||||||||||||
| Speaker | 2W * 8Ω * 2 | |||||||||||||
| Micro earphone | 3.5mm Stereo Headphone Output | |||||||||||||
| USB Type-C | Support upgrade and debug | |||||||||||||
| Media player | Video format | MPEG-1,MPEG-2,MPEG-4,H.263,H.264,H.265,VC1,VP8,RV etc.,Max. 3840x2160 | ||||||||||||
| Audio format | MP3,WMA,WAV, APE, FLAC, AAC, OGG,M4A,3GPP | |||||||||||||
| Text Format | EPUB, WORD, EXCEL, POWERPOINT, PDF, TXT | |||||||||||||
| E-Book format | PDF,TXT,CHM,DOC,EXCEL,EPUB,RTF,FB2 | |||||||||||||
| Image Format | JPG,BMP,PNG | |||||||||||||
System management |
APK installation | APK installation | ||||||||||||
| Root permission | Original Android system,open root permissions, system customization | |||||||||||||
| Remote control | Real-time remote monitoring, system crash self-recovery, 7*24 hours unattended. | |||||||||||||
| OTA upgrade | Support OTA remote upgrades | |||||||||||||
| Others | Gravity sensor | support G-sensor | ||||||||||||
| POE function | support POE (optional, default none) | |||||||||||||
| OSD Language | Multilingual OSD includes Chinese and English,etc | |||||||||||||
| Accessories | Adapter | Power Adapter 12V/2A | ||||||||||||
| User manual | Standard | |||||||||||||
| Warranty Card | Standard | |||||||||||||
PACKAGING DETAILS
1, Packaging: film, foam and wooden case (international standard packaging), suitable for export.
2, Lead time: in 1 week for sample order, about 5 weeks for large order.
Our Services:
1) Original guarantee; 2) Competitive prices;
3) Offer 12 months of warranty; 4) Stable supply at least 3-5years; 5)Any question will be reply in 24 hours
PRODUCT SCENARIOS
OFFICE AND FACTORY
SUNCHIP: Digital Signage manufacturer in Shenzhen, China.
Our main products include Android ARM Board, Floor Standing Display, Wall Mounted Display, Stretched LCD Display, Open Frame Display and Android Media Player Advertising Box.
LOOKING FORWARD TO YOUR INQUIRY AND KIND COOPERATIONS!
WELCOME TO INQUIRE ME~
SUNCHIP mainly manufactures:
1, Android industrial Embedded ARM board: RK3588, RK3566, RK3568, RK3288, RK3399,
RK3328, RKPX30, RK3188, RK3128 etc.
2, 【4K】Android player box for digital signage advertising: RK3399, RK3288, RK3328 & RK3568.
3, 【8K】Android Player Box for Industrial-Control Application: RK3588.
4, Open frame LCD display signage: 8inch, 10.1inch, 13.3inch, 15.6inch, 21.5inch etc.
5, SKD Kit: Android board + LCD panel with touch or not:
7inch, 8inch, 10.1inch, 13.3inch, 15.6inch.
6, Other types of Wall Mounted / Floor Standing / Desktop LCD digital signage.
7, Embedded touch desk: such as 32inch.
8, Face recognition temperature detection terminal machine: such as 8inch.
[You can also tell us your detailed requirements, so that we advise you a matched solution]
