Product Details:
|
| Product Type: | Android All In One Advertising | Product Description: | 23.1'' Android All In One Advertising |
|---|---|---|---|
| CPU&GPU: | RK3128,quad-core,Cortex A7,1.2G GPU Mali-400MP2 | LCD Panel: | 23.1'' |
| RAM: | 1GB/2GB (optional) | ROM: | 8GB/16GB/32GB(optional) |
| Operating System: | Android 6.0 | Resolution: | IPS 1920*158 |
| Contrast Ratio: | 3000:1 | Brightness: | 500cd/m2 |
| WiFi: | 802.11 B/g/n_2.4G (optional) | BT: | Support 4.0 |
| Network: | 10M/100M Ethernet; | 4G LTE: | Support 4G(optional, Default None) |
| OTA Upgrade: | YES | Gravity Sensor: | YES |
| POE Function: | YES (optional, Default None) | ||
| High Light: | long lcd screen,ultra wide lcd display |
||
Stretched bar lcd 23.1 inch black digital signage advertising board display from Sunchip
Stretched LCD Bar Display--AD-23.1ʺ-RK3128
Overview:
RK3128 Android all in one board, using Rockchip RK3128 quad-core chip program to support Google Android6.0 system. Support the mainstream audio and video formats and image decoding. Can support the highest resolution 1280 * 720, using a single MIPI interface LCD panel. support 1080P video playback. Rich interface, make the product more common, is widely used in advertising, one machine, security, industrial control and other intelligent control. Because of its hardware platform, Android intelligent features, in the need for human interaction, network equipment, interactive, intelligent terminal platform can be used.
Characteristic:
1, High performance. RK3128 chip with quad-core Cortex-A7, up to 1.2GHz frequency.
2, High stability. RK3128 Andrews one board, in hardware, software, increase their own unique technology to ensure product stability, you can make the final product to 7 * 24 hours unattended.
3, High level of integration RK3128 Andrews integrated board integrated Ethernet, wifi, amplifier, SD card, and so on, greatly simplifying the machine design. Slim-style motherboard design allows the machine design more beautiful.
4, High scalability 3 USB ports, can expand more external devices.
PRODUCTS SPECIFICATIONS
| System | CPU | RK3128,quad-core,Cortex A7,1.2G GPU Mali-400MP2 | ||||||||||||
| RAM | 1GB/2GB (optional) | |||||||||||||
| Storage | 8GB/16GB/32GB(optional) | |||||||||||||
| Operation system | Android 6.0 | |||||||||||||
| Display | LCD panel | 23.1" | ||||||||||||
| Resolution | IPS 1920*158 | |||||||||||||
| Contrast ratio | 3000:1 | |||||||||||||
| Brightness | 500cd/m2 | |||||||||||||
| Network | WiFi | 802.11b/g/n(802.11a/b/g/n/ac optional) | ||||||||||||
| Buletooth | Buletooth 4.0 | |||||||||||||
| Mobile Network | Built in 3G/4G LTE(optional, default none) | |||||||||||||
| Ethernet | 10M/100M Ethernet | |||||||||||||
| Interface | USB interface | support USB host*2 | ||||||||||||
| Micro USB | USB_OTG*1 | |||||||||||||
| DC | DC power supply 12V input | |||||||||||||
| TF card | Maximum support 32GB | |||||||||||||
| RJ45 | Ethernet port | |||||||||||||
| Speaker | 2W * 8Ω * 2 | |||||||||||||
| Media player | Video format | MPEG-1,MPEG-2,MPEG-4,H.263,H.264,H.265,VC-1,VP8,MVC etc.,max support 1080p | ||||||||||||
| Audio format | MP3,WMA,WAV, APE, FLAC, AAC, OGG,M4A,3GPP format | |||||||||||||
| Image Format | Support JPG,BMP, PNG,etc,support image rotation/slide show/zoom | |||||||||||||
System management |
APK installation | APK installation | ||||||||||||
| Root permission | Original Android system,open root permissions, system customization | |||||||||||||
| Remote control | Real-time remote monitoring, system crash self-recovery, 7*24 hours unattended. | |||||||||||||
| OTA upgrade | Support OTA remote upgrades | |||||||||||||
| Others | Gravity sensor | support G-sensor | ||||||||||||
| POE function | support POE (optional, default none) | |||||||||||||
| OSD Language | Multilingual OSD includes Chinese and English,etc | |||||||||||||
| Color | Black | |||||||||||||
| Accessories | Adapter | Power Adapter 12V/2A | ||||||||||||
| User manual | Standard | |||||||||||||
| Warranty Card | Standard | |||||||||||||
PRODUCT SCENARIOS
PACKAGING DETAILS
1, Packaging: film, foam and wooden case (international standard packaging), suitable for export.
2, Lead time: in 1 week for sample order, about 5 weeks for large order.
OFFICE AND FACTORY
SUNCHIP: Digital Signage manufacturer in Shenzhen, China.
Our main products include Android ARM Board, Floor Standing Display, Wall Mounted Display, Stretched LCD Display, Open Frame Display and Android Media Player Advertising Box.
